Mold type DC-DC Converter


CR1T15-15

CR1T15-15
  • Product Code: CR1T15-15
  • Use: For measurer
  • Maximum Input Voltage: AC500V
  • Operating Temperature: -20~+70℃
  • Input: DC15V± 10%
  • Output: 5V/50mA ± 15V/± 20mA
  • Number of Output: 3
  • Efficiency Rate: 72%
  • Option: Low input protection, Over-current protection
  • Size: 32(W)x20(D)x11(H)(mm)

CL4S05-05

CL4S05-05
  • Product Code: CL4S05-05
  • Use: For train car
  • Maximum Input Voltage: AC500V
  • Operating Temperature: -25~+85℃
  • Input: DC4.5V～6V
  • Output: 5V/800mA(4W)
  • Number of Output: 1
  • Efficiency Rate: 78%
  • Option: Over-current protection
  • Size: 32(W)x20(D)x11(H)(mm)

CH3D15-12

CH3D15-12
  • Product Code: CH3D15-12
  • Use: For measurer
  • Maximum Input Voltage : AC500V
  • Operating Temperature: -20~+70℃
  • Input: DC12V± 10%
  • Output:±15V/± 100mA(3W)
  • Number of Output: 2
  • Efficiency Rate: 80%
  • Option: Low input protection, Over-current protection
  • Size: 44(W)x10.5(D)x20(H)(mm)

CX3T15-05

CX3T15-05
  • Product Code: CX3T15-05
  • Use: For medical equipment
  • Maximum Input Voltage: AC2,000V
  • Operating Temperature: -20~+70℃
  • Input: DC5V± 5%
  • Output: 5V/550mA, ± 15V/± 30mA(3W)
  • Number of Output: 3
  • Efficiency Rate: 68%
  • Option: Over-current protection
  • Size: 38(W)x38(D)x8(H)(mm)

CR5F15-24

CR5F15-24
  • Product Code: CR5F15-24
  • Use: For Controller
  • Maximum Input Voltage: AC1,800V
  • Operating Temperature: -20~+70℃
  • Input: DC24V± 20%
  • Output: 15V/80mA 3ch, 15V/130mA 1ch (5.6W)
  • Number of Output: 4
  • Efficiency Rate: 70%
  • Option: Over-current protection
  • Size: 112(W)x19.5(D)x12(H)(mm)

CR6E24-30

CR6E24-30
  • Product Code: CR6E24-30
  • Use: For measuring system
  • Maximum Input Voltage: AC500V
  • Operating Temperature: -20~+75℃
  • Input: DC15V± 5%
  • Output: 24V/23mA 3ch, 15V/10mA 8ch (5.6W)
  • Number of Output: 16
  • Efficiency Rate: 60%
  • Option: Low input protection, breaker, Individual over-current protection for all output
  • Size: 66(W)x36(D)x12.5(H)(mm)
  • Radiator plate size: 66(W)x66(D)x1(T)(mm)

CR7T15-05

CR7T15-05
  • Product Code: CR7T15-05
  • Use: For Medical equipment
  • Maximum Input Voltage: AC500V
  • Operating Temperature: -20~+70℃
  • Input: DC24V± 5%
  • Output: 5V/1.2A, ± 15V/± 30mA (7W)
  • Number of Output: 3
  • Efficiency Rate: 78%
  • Option: Over-current protection
  • Size: 48(W)x48(D)x8(H)(mm)

CX8T15-03

CX8T15-03
  • Product Code: CX8T15-03
  • Use: For PCI board
  • Maximum Input Voltage: AC500V
  • Operating Temperature: -20~+70℃
  • Input: DC3.0V～5.5V
  • Output: 5V/1000mA, ± 15V/± 100mA (8W)
    or 5V/400mA, ± 15V/± 200mA (8W)
  • Number of Output: 3
  • Efficiency Rate: 78%
  • Option: Over-current protection
  • Size: 50(W)x36(D)x12.5(H)(mm)
